AGC Fluon LM-ETFE LM-2300N/LM-2150 Powder Resins Engineering Plastic Raw Material Fluoropolymers Resin

AGC Fluon LM-ETFE LM-2300N/LM-2150 Powder Resins Engineering Plastic Raw Material Fluoropolymers Resin

Fluon LM-ETFE is a thermoplastic fluoropolymer with a lower melting point.

Their superior physical toughness and resistance to chemicals, UV and extreme temperatures make these resins ideally suited for a wide range of high performance products and components such as industrial electric wire and cable.

Fluon LM-ETFE has even better thermal stability, heat resistance, stress crack resistance and is more flexible and transparent than standard ETFE. The LOI (limiting oxygen index) is also improved. It can be processed at a wider range of temperatures due to its improved thermal stability and lower melting point.

Fluon LM-ETFE resins are modified to provide a 30 °C to 40 °C lower melting point than conventional ETFE resins. The wider temperature range allows for improved processability, flexibility and strength.

These low melting fluoropolymer resins are processable by conventional extrusion and injection molding techniques. They are also available in rotomolding, rotolining and adhesive grades.

Grade	Mean particle size	Thickness μm	Molding Method
LM-2300N	300 - 500 μm	more than 2000 μm	Rotational molding
LM-2150	30 -70 μm	～ 500 μm	Electrostatic powder coating
