ETFE TL-581(C)
Fluon®@ETFE is a tough fluoropolymer that has chemical resistance and electrical properties comparable to typical fluoropolymers, such as PTFE, PFA and FEP but performs better than ECTFE or PVdF because of its improved mechanical strength and moldability.
ETFE TL 581 powder is a Rotational molding, Highly corrosion resistant; reaction tanks, storage tanks, piping, pumps, tanker trucks, etc
Fluon@ ETFE Heat Resistant (HR) & High Temperature (HT) Resins These products give a higher service temperature and greater thermal stability compared with conventional ETFE
Designed for wire and cable extrusion, ‘HR' ETFE has an operating temperature window of -180°C - +180°C whereas ‘HT' ETFE can perform at 175°C and 200°C meeting automotive
standard LV112, ClassEand Class F.ETFE HT colour grades are also available.Fluon@ETFE Compound Grades Fluon@ETFE Compound Grades give improved properties compared to
standard ETFE resin. A variety of custom reinforcements and conductivity levels are available.These various filled grades grant enhanced properties, such as reduced mould shrinkage
improved wear resistance and increased flexural strenath.Fluon@ ETFE Powder Grades Fluon@ ETFE is available in oowder form for non-stick and corrosion-resistant applications.It is
applied by electrostatic coating, fluid bed dip coating and rotolining
| Grade | Particle Size (μm) | Application Thickness | FDA | Electrostatic Spray Coating | Rotolinig | Fluid dip coatin | Applications |
| Z-8820X | 20-30 | 50-120μm | v | v | v | Thin coatings Non-stick for cookware Top coat for ZL520/521 | |
| ZL-520N | 70-80 | up to 800μm | v | Corrosion resistance (20% carbon fibre added | |||
| ZL-521N | 50-60 | up to 800μm | v | Top coat for ZL520N (5% carbon fibre added | |||
| TL-581 | 250-300 | 2-5mm | v | v | Corrosion protection for severe conditions | ||
| TL-081 | 80-150 | up to 800μm | v | v | v | Reactors, vessels, tanks pipeliners, pump housings | |
| LM-2150 | 60-70 | up to 800μm | v | v | Non-stick anti-corrosion coatings | ||
| CP-801XBK | 50-150 | up to 800μm | v | Anti-corrosion coatings |
Why Choose us |
CISKO NEW MATERIAL- Who is focus on the high temperature engineering resin & special raw material more then 15 years experience. Our main products include TPI/PI, PAI, PEEK, PEI, PPSU, PSU, PES,PVDF,ECTFE,PFA,ETFE,FEP,FKM,LCP, PPS,PPA, PA12, PA11,TPE,PCL,PP Compound and so on |
The material market applications: |
>Aircraft interiors , Auto parts,Electrical & Electronics components applications |
>Healthcare & Medical Instrument, food service applications |
>Plumbing , wire insulation, industrial applications |
>Green Hydrogen, anti-corrosion(coating) applications |
